Slotlight Infinity | LynX® inside

ZL 1903 HC DE 1024 Krankenhaus KE 2e16d0ba fill 1920x1920
Zumtobel Slotlight Infinity with LynX® inside

Connected lighting in a connected world

Zumtobel and LynX® bring you the world's first continuous light line controlled by manual interventions, automatically in function of scenarios or reasoning based on artificial intelligence.

The commands are sent wirelessly via Bluetooth or WiFi. A unique lighting concept that meets the highest requirements in terms of architecture and lighting technology and also provides functional added value for your organisation.

The end result is a high-quality lighting solution that is carefully integrated into the architecture and presents itself as a continuous row of light:

  • Consistently linear design with high precision up to 50m
  • Long light lines without interruption and dark spots
  • Uniform illumination, even around corners
  • Each LED can be individually controlled in colour and intensity
Explode01 close Lifeline No DOF

Slotlight Infinity (Slim)

ZS SLI F Einzelleuchte D ID 1700
Slotlight InfinitySlotlight Infinity Slim
Installation
Recessed (ceiling/wall), surface-mounted, suspended, technically recessed (modular ceiling, plasterboard)
Recessed (ceiling/wall), surface-mounted, suspended, technically recessed (modular ceiling, plasterboard)
Dimensions (mm)
76x98
45x64
Casing colours
Grey, white or black
Grey, white or black
Opal diffusor (cover)
Reception areas, corridors, living rooms and break-out areas
Reception areas, corridors, living rooms and break-out areas
Office diffusor (cover)
Home office, office buildings, school and meeting rooms
Home office, office buildings, school and meeting rooms
B0163 ZUMTOBEL SLOTLIGHT Pendant 2e16d0ba fill 1920x1067 2B0163 ZUMTOBEL SLOTLIGHT Recesse 2e16d0ba fill 1920x1067 6 Zk0q4 AV3V4
Explode02 v2 small2
cutting-edge technology inside

Product details

Zumtobel LynX® inside has a minimalist design and, at first sight, looks like comparable modern lighting fixtures. Inside, however, it is chock-full of amazing cutting-edge technology. The result is an elegant design, with infinitely many light communication possibilities.

Explode001 close Case Closed
Metal case

A sturdy, anodised aluminium case with powder paint coating (RAL 9005 mat, fine grain) offers optimal protection and minimalist design.

Explode001 close bevestiging
Fastening system

Includes stainless steel fastening system, with magnets suitable for both a pending (hanging) and flush mounted (built-in) and surface mounted (built-out) installation.

Explode001 close Cover
Diffuser (cover)

Mat acrylic glass (47 mm) diffuser on a roll of 25 m for a uniform distribution of the produced light. Cut to size and ´easy click´ onto the metal case.

Explode001 close LED
LED line

16 LEDs per metre, 108 white and 108 RGB. Controlled individually or by group, in both colour and intensity.

Explode001 close WIFI on Strip
WiFi/Bluetooth antenna

Bluetooth 4.2 BR EDR BLE, in order to accurately locate objects and people. WiFi radio: 802.11 b/g/n 2.4 GHz, which receives commands wirelessly and converts them into functional light.

Explode001 close Lifeline
Lifeline driver

Receives the commands via WiFi or Bluetooth, communicates with lifeline controller and addresses the individual or grouped LEDs.

Explode001 close Dali
DALI-compliant

DALI-compliant: Digital Addressable Lighting Interface is an open digital standard that is used worldwide for the control of lighting.

Explode001 close Batterij
Power/emergency battery

Interlink power supply between the LEDs 220 V/60 W (max 30 W/m) with optional replaceable LiPo battery (2200 mAh, 14.8 V) in accordance with European application standard NBN-EN 1838.Bluetooth antenna.

USP Slider 2880x1600 SLOTLIGHT 1 2e16d0ba fill 1280x711
Explode close up On no DOF
